Cissell HF234 - Manual (Page 5)

HF234
Capacity (dry weight)
1/11 21,3 kg
1/10 23,4 kg
1/9 26 kg
Cylinder
Diameter 750 mm
Depth 530 mm
Volume 234 Lit
Cabinet
Height 1505 mm
Width 900 mm
Depth 985 mm
Front loading
Diameter door opening 395 mm
Door height 630 mm
To center 820 mm
Speed
Wash 10 - 50 tr/min
Distribution 100 tr/min
Low spin 250 - 500 tr/min
High spin 500 - 1000 tr/min
G-factor
Low spin/high spin 74/ 373
Motoren (3-fasig)
4p. 1470 tr./min 3000W
Drain valve
Depend-O-Drain 3"
Water supply
Hard, soft, warm water 3/4"
Steam connection
Steam connection 3/8"
Heating
Electrical 230/400 V 12/15/18 kW
Electrical 400V 24 kW
Steam 6 bar
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm 1650x 1020x 1150 mm
Weight
Nett 570 kg
Brutt 630 kg
Technical data and dimensions
2
Technical data
