Cissell HF234 - Manual (Page 4)

Technical data and dimensions
2
Technical data
HF150 HF185
Capacity (dry weight)
1/11 13 kg 16,4 kg
1/10 14,5 kg 18 kg
1/9 16 kg 20 kg
Cylinder
Diameter 680 mm 680 mm
Depth 400 mm 500 mm
Volume 145 Lit 181 Lit
Cabinet
Height 1348 mm 1348 mm
Width 780 mm 780 mm
Depth 840 mm 940 mm
Front loading
Diameter door opening 395 mm 395 mm
Door height 565 mm 565 mm
To center 770 mm 770 mm
Speed
Wash 10 - 50 tr/min
Distribution 85 tr/min
Low spin 250 - 500 tr/min
High spin 500 - 1000 tr/min
G-factor
Low spin/high spin 94 / 380
Motoren (3-fasig)
4p. 1470 tr./min 2200W
Drain valve
Depend-O-Drain 2"
Water supply
Hard, soft, warm water 3/4"
Steam connection
Steam connection 3/8"
Heating
Electrical 230/400 V 12/15/18 kW
Electrical 400V 21/24 kW
Steam 6 bar
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) mm 1495x850x930 - 1495x850x1030
Weight
Nett 424 kg 454 kg
Gross 440 Kg 470 kg
