Specifications – Toa C-BC450PM User Manual
Page 4
Stainless steel
156 (W) x 150 (H) x 62 (D) mm (6.14" x 5.91" x 2.44")
660 g (1.46 lb)
ш
90 -
ш
340 mm (
ш
3.54" -
ш
13.4")
C-CV44-3, C-CV854D-3 *
Finish
Dimensions
Weight
Applicable pole diameter
Applicable camera
5. SPECIFICATIONS
133-02-00075-00
URL: http://www.toa.jp/
* When installing this applicable camera, the C-BC850W Wall Mounting Bracket should be obtained
separately.
YS-60B
(option)
Plain washer
Spring washer
Screw M4
Screw length:
10 mm or more
C-BC850W
Wall mounting bracket (option)
C-BC450PM
4.2. Attaching the C-BC850W
• Attach the wall mounting bracket supplied with the C-BC850W to the C-BC450PM using 4 sets of M4
screws, plain washers, and spring washers.
• For mounting details of the wall mounting bracket, refer to the instruction manual attached to the wall
mounting bracket.
