Toa PE-154EN - Manual (Page 4)

[Top]
[Front]
[Bottom]
ш186 (ш7.32)
4-ш5 (ш0.2)
ш16 (ш0.63)
ш100 (ш3.94)
58 (2.28)
36 (1.42)
251 (9.88)
Max. 5000
90
23 (0.91)
50 (1.97) 75 (2.95)
(16.4 ft)
(3.54)
Cable
(from the amplifier)
Cable
(to the next speaker)
COM
HOT
COM
HOT
Cable
(from the amplifier)
Screw terminal
Cable
(to the next speaker)
4
Rotary switch
2 kΩ
1 kΩ
670 Ω
COM
8 Ω
0
SP1
SP2
COM
HOT
OFF
OFF
OFF
Matching
transformer
Network
circuit
(Factory-preset wiring)
Thermal fuse
(84°C or 183.2°F)
Terminal
block
6. WIRING DIAGRAM
5. DIMENSIONAL DIAGRAM
Unit: mm (in)
[When making a bridge connection]
Connect both the amplifier cable and lead-out
speaker cable (for bridge wiring) of the same
polarity together to the corresponding terminal of
the screw terminal.
