6. SPECIFICATIONS
Notes
• The design and specifications are subject to change without notice for improvement.
• The Specifications data was measured in an anechoic chamber, according to EN 54-24.
• Reference axis: Axis is on the center of grill surface and perpendicular to the grill surface.
• Reference plane: Plane is on the grill surface and perpendicular to the reference axis.
• Horizontal plane: Plane is containing the reference axis and perpendicular to the reference plane.
Model
PC-1869EN
PC-2369EN
Standards
Certified to the European Standard
Certified to the European Standard
EN 54-24: 2008
EN 54-24: 2008
Loudspeaker for voice alarm systems
Loudspeaker for voice alarm systems
for fire detection and fire alarm systems
for fire detection and fire alarm systems
Certified to the International Standard ISO 7240-24: 2010
Sound-system loudspeaker for fire detection and fire alarm systems
Environment Type
Type A
Rated Noise Power
6 W (100 V line), 3 W (70 V line)
Rated Impedance
100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 6.7 kΩ (1.5 W), 13 kΩ (0.8 W)
70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 6.7 kΩ (0.8 W), 13 kΩ (0.4 W)
Sensitivity
94 dB (1 W, 1 m, 500 Hz to 5 kHz pink noise)
90 dB (1 W, 1 m, 100 Hz to 10 kHz
92 dB (1 W, 1 m, 100 Hz to 10 kHz
pink noise)
pink noise)
78 dB (1 W, 4 m, 100 Hz to 10 kHz
80 dB (1 W, 4 m, 100 Hz to 10 kHz
pink noise)
pink noise)
Max. SPL
98 dB (6 W, 1 m, 100 Hz to 10 kHz pink noise)
86 dB (6 W, 4 m, 100 Hz to 10 kHz pink noise)
Frequency Response
100 Hz – 18 kHz
70 Hz – 18 kHz
Coverage Angle (–6 dB)
Horizontal: 165° (500 Hz), 175° (1 kHz),
Horizontal: 160° (500 Hz), 170° (1 kHz),
165° (2 kHz), 70° (4 kHz)
160° (2 kHz), 60° (4 kHz)
Vertical:
165° (500 Hz), 175° (1 kHz), Vertical: 160° (500 Hz), 170° (1 kHz),
165° (2 kHz), 70° (4 kHz)
160° (2 kHz), 60° (4 kHz)
Speaker Component
12 cm (5") cone
16 cm (6.5") cone
Cable Connection
Screw terminal (steatite)
Applicable Cable Size
Outer diameter:
ш8.0 – ш12.5 mm
Conductor:
Solid wire or 7-core wire
No bridge connection: 0.8 – 10 mm
2
(AWG18 – 7) for solid wire,
0.8 – 8 mm
2
(AWG18 – 8) for 7-core wire
Bridge connection :
0.8 – 2.5 mm
2
(AWG18 – 13) for solid wire,
0.8 – 1.5 mm
2
(AWG18 – 15) for 7-core wire
Finish
Baffle: Steel plate, off white (RAL 9010 or equivalent color), paint
Grille: Surface-treated steel plate net, off white (RAL 9010 or equivalent color),
paint
Dimensions for Fixing
ø150 ± 3 mm (ш5.91 ± 0.12")
ш200 ± 3 mm (ø7.87 ± 0.12")
Hole
Dimensions
ø180 x 80 (d) mm (ø7.09 x 3.15")
ø230 x 110 (d) mm (ø9.06 x 4.33")
Weight
820 g (1.81 lb)
1.1 kg (2.43 lb)
