Appendix A: WPIM Cable Specifications
A-12 CSX200 Installation Guide
WPIM-E1
This section provides the Cabletron Systems part number and connector specifications for the
WPIM-E1 interface cable.
Table A-18 shows the WPIM-E1 connector number, cable and interface type, connector type and
part number information.
Table A-19 provides WPIM-E1 network interface cable pin assignments.
Table A-18 WPIM-E1 Connector Information
Connector Number Cable and Interface Type Connector Type Part Number
1
E1 RJ45 9372095
2
Table A-19 Network Interface
Pin Signal
1 Receive Ring
2 Receive Tip
3 Shield Ground
4 Transmit Ring
5 Transmit Tip
6 Shield Ground
7 Not Used
8 Not Used
