Appendix A: WPIM Cable Specifications
A-2 CSX200 Installation Guide
Table A-3 provides RJ48 DTE pin assignments.
Table A-4 provides RJ48 network pin assignments.
Table A-3 DTE Pin Assignments
Pin Signal
1 Receive Ring
2 Receive Tip
3 Not Used
4 Transmit Ring
5 Transmit Tip
6 Not Used
7 Shield Ground
8 Shield Ground
Table A-4 Network Pin Assignments
Pin Signal
1 Receive Ring
2 Receive Tip
3 Not Used
4 Transmit Ring
5 Transmit Tip
6 Not Used
7 Not Used
8 Not Used
