Tie Down Base - Stand Mounting - Manual

TIE DOWN ENGINEERING • 255 Villanova Drive SW • Atlanta, GA 30336
www.tiedown.com (404) 344-0000 Fax (404) 349-0401
022213,A1308
Mounting Base Stand
GalvX #86911 / Galvanized #86929
MAKE YOUR DOCK A DESTINATION
Instruction Sheet #08190
Tools Required:
Screw Driver
GalvX Dual Coat Finish - #86911 Parts List
# Part # Qty Description
1 86911-1A 1 Mounting Base
2 10841 4 3/8" Washer
(For use with Treasure Garden Umbrella Stand)
3 12159 4 8mm x 1.25" Nyloc Nut
(For use with Treasure Garden Umbrella Stand)
4 10660 2 Knob(s)
Hot Dipped Galvanized Finish - #86929 Parts List
# Part # Qty Description
1 86929-1A 1 Mounting Base
2 10841 4 3/8" Washer
(For use with Treasure Garden Umbrella Stand)
3 12159 4 8mm x 1.25" Nyloc Nut
(For use with Treasure Garden Umbrella Stand)
4 10660 2 Knob(s)
1
3
2
4
