41
9 Digital Communication Interface
Interface Commands
Command Description
Command
Format Command
Example
Returned
Returned
Example Acceptable
Values
Stop program pc=s[top] pc=s
Continue program pc=c[ont] pc=c
Read program function pf pf pf: 9 pf: 3
Set program function to n pf= n pf=2 1 to 4
Configuration Menu
Operating Parameters Menu
Read high limit hl hl hl: 9999 hl: 925
Set high limit hl=n hl=900 100–1200
Read soft cutout cuto cuto c: 9999.9 c: 1150.0
Set soft cutout setting: cu[tout]=n
Set soft cut-out to n degrees cu[tout]=n cu=500 0.0 to 1150.0
Read cut-out mode cm[ode] cm cm:{xxxx} cm: AUTO
Set cut-out mode cm[ode]=r[eset]/a[uto] Reset or Auto
Set cut-out to be reset manually cm[ode]=r[eset] cm=r
Set cut-out to be reset
automatically cm[ode]=a[uto] cm=a
Serial Interface Menu
Read serial sample setting sa[mple] sa sa: 9 sa: 1
Set serial sampling setting to n
seconds
sa[mple]= n sa=0 0 to 4000
Set serial duplex mode: du[plex]=f[ull]/h[alf] FULL or HALF
Set serial duplex mode to full du[plex]=f[ull] du=f
Set serial duplex mode to half du[plex]=h[alf] du=h
Set serial linefeed mode: lf[eed]=on/of[f] ON or OFF
Set serial linefeed mode to on lf[eed]=on lf=on
Set serial linefeed mode to off lf[eed]=of[f] lf=of
Cal Menu
Read CT n calibration parameter ct n ct1 ct n: 99.9C ct1: –10.0C
Set CT n calibration parameter to
n
ct n=n ct1=–10.0 0 to 12.00
Read CE n calibration parameter ce n ce1 ce n: 99.9C ce1: -10.1C
Set CE n calibration parameter to
n
ce n=n ce1=–10 –99.9 to 99.9
Table 3 Communications Commands Summary continued
