9150 Portable Furnace
User’s Guide
40
Command Description
Command
Format
Command
Example
Returned
Returned
Example
Acceptable
Values
Display Temperature
Read current set-point
s[etpoint]
s
set: 9999.99 {C or F}
set: 150.0 C
Set current set-point to n
s[etpoint]=n
s=450
Instrument
Range
Set temperature units:
u[nits]=c/f
C or F
Set temperature units to Celsius
u[nits]=c
u=c
Set temperature units to
Fahrenheit
u[nits]=f
u=f
Read scan function
sc[an]
sc
scan: {ON or OFF}
scan: ON
Set scan function:
sc[an]=on/of[f]
ON or OFF
Turn scan function on
sc[an]=on
sc=on
Turn scan function off
sc[an]=of[f]
sc=of
Read scan rate
sr[ate]
sr
srat: 999.99 {C or F}/min srat: 10.0 C/min
Set scan rate to
n degrees per
minute
sr[ate]=
n
sr=5
.1 to 99.9
Secondary Menu
Read proportional band setting
pr[op-band]
pr
pb: 999.9
pb: 15.9
Set proportional band to
n
pr[op-band]=n
pr=8.83
0.1 to 100
Read heater power
(duty cycle)
po[wer]
po
po: 999.9
po: 1
Ramp and Soak Menu
Read number of programmable
set-points
pn
pn
pn: 9
pn: 2
Set number of programmable
set-points to
n
pn=
n
pn=4
1 to 8
Read programmable set-point
number
n
ps
n
ps3
ps
n: 9999.99 {C or F}
ps1:
50.00 C
Set programmable set-point num-
ber
n to n
ps
n=n
ps3=50
1 to 8, Instru-
ment Range
Read program set-point soak
time
pt
n
pt3
ti
n: 999
ti1: 5
Set program set-point soak time
to
n minutes
pt
n=n
pt3=5
0 to 14400
Read program scan rate
px
n
px3
sr
n: 99.9
sr3: 11.3
Set program scan rate
px
n=n
px3=10
.1 to 99.9
Read program control mode
pc
pc
prog: {OFF or ON}
prog: OFF
Set program control mode:
pc=g[o]/s[top]/c[ont]
GO or STOP or
CONT
Start program
pc=g[o]
pc=g
Table 2 Communications Command Summary
