FieldPilot
®
Kit Contents
Unpack the installation kit and identify the required parts.
Item Part Number Description
Quantity
A
32-04040
Switch, Engage/Disengage ......................................................................................1
B
350-0037
Washer, Flat - 3/8” SST ...........................................................................................3
C
35-03196
Valve, FieldPilot, PWM, 7.9GPM, CC, w/ Master & Relief .......................................1
D
45-05822
Cable,PSI Switch, 15’, FieldPilot, to 2 Pos WP........................................................1
E
45-07704
Cable, SCM to Power, FieldPilot Valve & Master.....................................................1
F
45-10136
Harness, FieldPilot Valve, A, B, & Master ...............................................................1
G
60-04095
Bolt, Hex- 3/8-16 x 3-3/4” SST .................................................................................2
H
60-04095
Bolt, Hex- 3/8-16 x 1-1/2” SST .................................................................................1
I
60-04099
Set Screw, 10/24 X 3/8”, Cup Point Allen ................................................................1
J
60-07027
Nut, NyLock 3/8-16, SST .........................................................................................3
K
65-05162
Bracket, Hydraulic Block Mount ...............................................................................1
L
68-01152
Hose, Hydraulic - 3/8” x 53”, #8FORF x #8FORF90º ..............................................2
M
68-01170
Hose, Hydraulic - 3/8” x 38”, #8FORF x #6FORF90º ..............................................1
N
68-01256
Hose, Hydraulic - 1/4” x 42”, #6FJIC x #6FORF90º .................................................1
O
68-01257
Hose, Hydraulic - 1/4” x 20”, #6FORF x #6FORF ....................................................1
P
68-01267
Hose, Hydraulic - 3/8” x 49”, #8FORF x #6FORF90º ..............................................1
Q
68-02012
Shuttle Tee ...............................................................................................................1
R
68-02026
Adapter, Hydraulic Run Tee - #8 ORF .....................................................................2
S
68-02071
Adapter, Hydraulic Run Tee - #6 ORF .....................................................................2
T
68-02072
Adapter, Hydraulic 90º - #6MORF x #6FORF ..........................................................1
U
68-02073
Adapter, Hydraulic - #6MORF x #6MORB ...............................................................2
V
68-02080
Adapter, Hydraulic 90º - #6MJIC x #6MORB ...........................................................1
W
68-02110
Adapter, Hydraulic - #6FORF x #6MORB ................................................................1
X
68-02118
Adapter Hydraulic - M14 x 1.5 (6149) x #6MORF ...................................................3
Y
68-02159
Adapter, Hydraulic - #8MORF x #8MORB ...............................................................4
Z
68-02187
Adapter, Hydraulic #6 ORF, GPT (Gauge Port Tee) ................................................1
