11
FieldPilot ®
98-05217 R3
installation
If there are questions concerning the installation of the FieldPilot system on this vehicle, or due to the
changes in component specifications the parts supplied in the kit are not exactly as presented in this
document, please contact your dealer or TeeJet customer service representative for clarification before
installation. TeeJet Technologies is not responsible for misuse or incorrect installation of the system.
NOTE: BE VERY CAREFUL TO ABSOLUTELY SECURE ALL CABLES AND HOSES SO THAT THEY DO NOT
INTERFERE WITH THE MANY MOVING PARTS OF THE MACHINE!
Overview of the Machine
• Most of the FieldPilot system will install near the rear of the machine on the left hand side.
• Pressure, Tank, and LS connections will be at the rear of the machine in the Power Beyond ports of the SCV
stack.
• The steering lines will tee-in near the steering cylinder on the left side of the machine.
• The GPS will mount near the front of the machine on the hood.
NOTE: All references to left and right are stated as if the user is seated in the driver’s seat.
Figure 1-5: Preparing the FieldPilot Valve
Gps
Cable
entrance
Hydraulic
Connections
Fieldpilot
Valve
steering line
Connections
