FieldPilot ®
Kit CoNteNts
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
A 32-04040 Switch, Engage/Disengage ......................................................................................1
B 350-0037 Washer, Narrow Flat - 3/8”, SST ..............................................................................2
C 35-02183 Valve, FieldPilot PWM, 1.1GPM, OC .......................................................................1
D 45-07703 Harness, SCM .........................................................................................................1
E 45-10103 Harness, Valve .........................................................................................................1
F 60-04089 Bolt, Hex, 3/8-16 x 3-3/4” SST .................................................................................2
G 60-07027 Nut, NyLock 3/8-16, SST .........................................................................................2
H 65-05155 Bracket, FieldPilot Valve Mount ...............................................................................1
I 68-01236 Hose, Hyd - 1/2” x 70”, #8MORF X #8FJIC 90º .......................................................1
J 68-01237 Hose, Hyd - 1/2” x 78”, #8FORF X #8FJIC .............................................................1
K 68-01238 Hose, Hyd - 1/2” x 45”, #8FORF X #8FJIC .............................................................1
L 68-01239 Hose, Hyd - 3/8” x 83”, #6FORF X #6FJIC 90º ........................................................1
M 68-01240 Hose, Hyd - 3/8” x 192”, #6FJIC X #6FORF 90º ......................................................2
N 68-02071 Adapter, Hyd. Run Tee - #6 ORF .............................................................................3
O 68-02075 Adapter, Hyd. 90º - #6MORF x #8MORB ................................................................1
P 68-02078 Adapter, Hyd. 90º - #6MJIC x #6FJIC .....................................................................2
Q 68-02082 Adapter, Hyd. - #6MJIC x #8MORB ........................................................................3
R 68-02093 Adapter, Hyd. 90º - #8MJIC x #8FJIC .....................................................................1
S 68-02122 Adapter, Hyd. - #8MJIC x #12MORB .......................................................................2
T 90-50013 Cable Tie Kit, 15 ......................................................................................................2
U 91-07011 Steering Wheel Switch Kit .......................................................................................1
V 98-05214 Installation Manual, FP JD 6500, 6700 Hi-Cycle .....................................................1
