FieldPilot ®
12. VeriFY oPeration oF hYdraulics
and set the steering control rate
Clean and pick up the area around the vehicle and make certain that it is safe to operate. Start the engine
and check hydraulic connections for leaks. Rotate the steering wheel from one extreme to the other and back
to center, check for leaks. While steering through the extremes of movement, check the cables and hoses for
wear points and strain, adjust as necessary.
The final oil flow rate adjustment is accomplished through the Matrix console.
The target lock to lock time is 6 seconds. The valve frequency is 110. Refer to the
Matrix manual for further instructions.
NOTE: To activate the manual overrides, a tool such as a small screwdriver or allen wrench must be inserted
into the end of the coil to depress the override button.
WARNING: PINCH POINT HAZARD! To prevent serious injury or death, avoid unsafe practice
while manually operating hydraulic steering circuits. Keep others away and stay clear of
mechanical steering linkages.
13. coMPlete electronic installation
Refer to the owner’s manual supplied with the automated steering system to complete the electronic
installation and setup.
