5
FieldPilot ®
Item Part # Description Illustration
G 60-07027 Nut, SST, 3/8”_16 Nylock
H 65-05134 Bracket, Valve Mounting
I 68-01028 Hose, Hydraulic 3/8”
x 52”, #6FJICswiv x
#8FORFswiv90°
J 68-01029 Hose, Hydraulic 3/8”
x 45”, #6FJICswiv x
#8FORFswiv90°
K 68-01030 Hose, Hydraulic 1/4” x 43”,
#6FJICswiv both ends
L 68-02012 Hydraulic Load Shuttle
#6FORB
M 68-02019 Adapter, Hydraulic
#6MORB_#6MJIC
N 68-02026 Adapter, Run Tee, #8ORF,
F-M-M
