3
LH FOREST LOGGER IS A VERY EASILY OPERATEABLE MONITOR WHICH IS
ABLE TO MEASURE THE FOLLOWING:
* Forward speed m/min
* Distance in metres (trip and total) (5 registers)
* Time
All encoded and gathered data are stored in the memory, also if power, deliberately or
not, is cut off.
DESCRIPTION OF THE SYSTEM
The below illustration shows the FOREST LOGGER system with electronic box and
sensors.
FOREST LOGGER: Electronic box with operation, display and sensor connections.
Speed sensor: The sensor sends an electric signal to the FOREST LOGGER
each time a magnet passes the sensor.
