FITTING THE MONITOR
Fit the monitor in the cab in reach of the operator. Connect the monitor to the
tractor’s 12V supply via the 2-pin power plug.
FITTING THE JUNCTION BOX
Fit the junction box on the front of the seed drill in the middle. When the cables
are connected in the box, make sure that each cable has a drip off bend so that
water does not run along the cable and into the junction box.
Make sure that the holes through the rubber grommets are not too large,
make the hole as small as possible and push the cable through.
