cooling cycle remains ‘‘on’’ until the room temperature drops to
point that is slightly below the cooling control setting of the room
thermostat. At this point, the thermostat ‘‘breaks’’ the circuit
between thermostat terminal R to terminals Y and G. These open
circuits de-energize contactor coil C and ICM board. The con-
denser and compressor motors stop. After the time delay setting
selected on the Easy Select™ board (See Easy Select Section) , the
blower motor stops. The unit is in a ‘‘standby’’ condition, waiting
for the next ‘‘call for cooling’’ from the room thermostat. The 5
minute compressor delay also applies to heat pump heating mode.
ELECTRICAL DATA & SCHEMATICS—ICM FIOP
Step 1—Physical Data & Electrical Schematics
Use the Physical Data and Electrical Tables on the following pages
for information that applies to Carrier Puron® units with the ICM
indoor motor FIOP.
AIRFLOW & TEMPERATURE RISE TABLES—ICM FIOP
Step 2—Tables For System Set-Up
Use the Airflow and Temperature Rise Tables on the following
pages for information that applies to Carrier Puron® units with the
ICM indoor motor FIOP.
CARE AND MAINTENANCE
Indoor Blower and Motor
NOTE: All motors are pre-lubricated. Do not attempt to lubricate
these motors. For longer life, operating economy, and continuing
efficiency, clean accumulated dirt and grease from the blower
wheel and motor annually.
Disconnect and tag electrical power to the unit before
cleaning and lubricating any blower motor and wheel. On
units with gas heat, turn off the gas supply before disconnect-
ing the electrical power. Failure to adhere to this warning
could cause serious injury or death.
To clean the blower motor and wheel:
1. 1. Remove and disassemble blower assembly as follows:
a. Remove unit access panel.
b. Carefully pivot blower access panel outward towards the
electrical box. Route wiring above blower access panel.
c. Disconnect the 5 and 16 pin plugs at the blower motor.
d. On all units, remove blower assembly from unit. Remove
screws securing blower to vertical partition and slide
assembly out. Be careful not to tear insulation in blower
compartment.
e. Ensure proper reassembly by marking blower wheel and
motor in relation to blower housing before disassembly.
Table 1—ICM FIOP Physical Data—Unit 48GP
THIS DATA APPLIES TO 48GP UNITS WITH THE ICM INDOOR MOTOR FIOP
UNIT SIZE 48GP
024040
024060
030040
030060
036060
036090
042060
042090
NOMINAL CAPACITY (ton)
2
2
2-1/2
2-1/2
3
3
3-1/2
3-1/2
OPERATING WEIGHT (lb.)
290
290
313
313
321
321
382
382
COMPRESSORS
Quantity
Scroll
1
REFRIGERANT (R-410A)
Quantity (lb.)
5.0
5.0
5.5
5.5
6.9
6.9
9.0
9.0
REFRIGERANT METERING DEVICE
Orifice ID (in.)
AccuRater™ Piston
.057
.057
.057
.057
.065
.065
.070
.070
CONDENSER COIL
Rows...Fins/in.
Face Area (sq ft)
1...17
10.9
1...17
10.9
1...17
12.7
1...17
12.7
2...17
9.1
2...17
9.1
2...17
12.3
2...17
12.3
CONDENSER FAN
Nominal Cfm
Diameter (in.)
Motor HP (Rpm)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
EVAPORATOR COIL
Rows...Fins/in.
Face Area (sq ft)
3...15
3.7
3...15
3.7
3...15
3.7
3...15
3.7
3...15
3.7
3...15
3.7
3...15
4.7
3...15
4.7
EVAPORATOR BLOWER
Nominal Airflow (Cfm)
Size (in.)
Motor (HP)
800
10 X 10
1/2
800
10 X 10
1/2
1000
10 X 10
1/2
1000
10 X 10
1/2
1200
11 X 10
3/4
1200
11 X 10
3/4
1400
11 X 10
3/4
1400
11 X 10
3/4
FURNACE SECTION*
Burner Orifice No. (Qty...Drill Size)
Natural Gas
Burner Orifice No. (Qty...Drill Size)
Propane Gas
2...44
2...50
2...38
2...46
2...44
2...50
2...38
2...46
2...38
2...46
3...38
3...46
2...38
2...46
3...38
3...46
HIGH-PRESSURE SWITCH (psig)
Cutout
Reset (Auto)
610 ± 15
420 ± 25
LOSS-OF-CHARGE/LOW-
PRESSURE SWITCH
(Liquid Line) (psig)
Cutout
Reset (Auto)
20 ± 5
45 ± 10
RETURN-AIR FILTERS (in.)
Throwaway
20 X 20 X 1 20 X 20 X 1 20 X 20 X 1 20 X 20 X 1 20 X 24 X 1 20 X 24 X 1 24 X 30 X 1 24 X 30 X 1
* Based on altitude of 0 to 2000 ft.
