9

98-05266 R0 US

Matrix

®

570VT ● ISOBUS

CHAPTER 2 – SYSTEM SETUP

System Setup is used to configure cultural and console settings.
NOTE: All settings are automatically saved when selected.

Figure 1-11: Master Screen

Figure 1-12: System Setup Tab

To access the System Setup screens:
1. Select MATRIX VT SETUP KEY from Master

Screen.

2. Select from:

►Culture – used to configure Units ,

Language and Time Zone .

►Console – used to configure Volume ,

LCD Brightness , Virtual Terminal Number

and Screen Calibration settings, as well as

view About information and Save system software

information .
