TeeJet MATRIX 570VT Software version 1.00 - Manual (Page 7)

7
98-05266 R0 US
Matrix ® 570VT ● ISOBUS
Language
Figure 1-13: Language
Figure 1-14: Time Zone
Languages defines the system language.
1. Press CULTURE ICON .
2. Press LANGUAGE ICON .
3. Press UP/DOWN ARROW ICONS to change between languages.
4. Press
►PAGE RIGHT ARROW to proceed to Time Zone.
►SYSTEM SETUP TAB to return to main System Setup screen.
Time Zone
Time zone establishes the local time zone.
1. Press CULTURE ICON .
2. Press TIME ZONE ICON .
3. Press UP/DOWN ARROW ICONS to select the appropriate time zone.
4. Press
►CHECKERED FLAG to complete Culture Setup.
►SYSTEM SETUP TAB to return to main System Setup screen.
Time zones are listed alphabetically by continent then city. A list of the continents
and cities is in Appendix A.
CONSOLE
Console Setup is used to configure Volume, LCD Brightness, Virtual Terminal Number and Screen Calibration settings, as well as view
About information and Save system software information.
Figure 1-15: Console
Figure 1-16: Volume
1. Press CONSOLE ICON .
2. Select from:
►Volume – adjusts the volume level of the audio speaker
►LCD Brightness – adjusts the brightness of the console display
►Virtual Terminal Number – defines the unique number for this specific VT
terminal
►Touch Screen Calibration – used to force a touch screen calibration
►About/Save – displays the system software version as well as the
software versions of modules connected to the CAN bus
OR
Press PAGE RIGHT ARROW to cycle through all settings.
Volume
Volume adjusts the volume level of the audio speaker. Range is 0 - 100.
1. Press CONSOLE ICON .
2. Press VOLUME ICON .
3. Press the UP/DOWN ARROW ICONS to adjust volume level.
• Higher the number, the louder the sound
• Lower the number, the softer the sound
4. Press
►PAGE RIGHT ARROW to proceed to LCD Brightness.
►SYSTEM SETUP TAB to return to main System Setup screen.
