CHAPTER 1– PRODUCT OVERVIEW

The Matrix 570VT is designed to provide years of service under typical agricultural operating conditions. A tight fitting enclosure, combined

with rubber covers for all connectors mean that typical dusty environments will not cause operational problems. While occasional splashing

of water will not damage the unit, the Matrix 570VT is not designed for direct exposure to rain. Take care not to operate the Matrix in wet

conditions.
Figure 1-1: Console Front & Back

Power Button

Power Button

USB Port with Rubber Cover

USB Port with Rubber Cover

Standard RAM Bracket

Bright Touch Screen

Rubber Connector

Covers

Integrated RAM Mount

Speaker

Recessed Connectors

Connection ports are not used

Power Connection
