4.4 Main Menu, Inputs
4.4.1 DVB-S2 reception
In the following you can find the information for setting the reception parameters for the
satellite reception:
The menu is only available for the following products:
Article no. Product name
0000/5972 TechniNet IP DVB-S2/IP DVB-S2 IRD-card (x6 Multicast channels)
0000/5977
TechniNet IP DVB-S2/IP 32M DVB-S2 IRD-card (x32 Multicast
channels)
You are within the main menu,
Section: Inputs.
Tuner input, DVB-S2, DVB-S
The input of the LO-Frequency is in MHz.
Local oscillator frequency (LO) of the LNB’s
09750MHz =
LO Frequency for
Low-Band
10600MHz =
LO Frequency for
High-band
The input of the frequency is in MHz.
Satellite Down-Link Frequency
The input of the symbol rate is in kbaud.
Symbol rate
ENTER
 
Main Menu
Inputs ->
Inputs
DVB-S2 ->
ENTER
 
LNB Frequency
10600MHz
ENTER
ENTER
 

Satellite Frequency
11836MHz
ENTER
ENTER
 

Symbol Rate
27000KBaud
ENTER
ENTER
 

