4.2 Connection of the programmer Remote Control
For the local operation of the modules, the cable connected TechniNet IP Programmer will be
connected to the 15 pol. D-Sub-connector at the front panel of the module. It can only
communicate with one module at one time.
Picture: 2, Programmer 0000/5971
After the first connection of the programmer
welcome does apply.
The Display shows the type of card and the
currently set IP address.
IP-Address by delivery is: 10.10.70.48
You are in the main menu and you are able to
choose Input, Output or System.
Welcome
ENTER
0000/5972
IP:10.10.70.48
ENTER
Main Menu
Inputs ->
 
Main Menu
Outputs ->
 
Main Menu
System ->
