Page 6: Assemble the net frame
NET FRAME
ASSEMBLE THE NET FRAME
STEP 1
STEP 1
COUPLER
FITTING
G
GET PARTS “A”, “B”, AND “C”.
THERE ARE TWO PART “B”’s, FOUR PARTS TOTAL.
GET THREE EYEBOLTS AND
FOUR COUPLERS WHILE YOU ARE AT IT
LAY IT OUT ON THE FLOOR
C
A
B
B
B
B
NOTE:
INSERT AND TIGHTEN
EYEBOLTS IN PART C
BEFORE ASSEMBLING FRAME
(3 BOLTS TOTAL)
STUB UP
4
4
MVP/XXL
ASSEMBLY MANUAL
SWINGAWAY
SWINGAWAY
SPORTS PRODUCTS
SPORTS PRODUCTS
SPORTS PRODUCTS
THE "SwingAway®" PRODUCT IS PROTECTED UNDER US PATENTS 5,795,250 AND 7,914,400.
