Page 15: Put the top boom in, Do a “walk-around” 13 13
5 INCHES IN
JK
R
STEP 10
STEP 10
PUT THE TOP BOOM IN
GET PART JK AND THE TOP BOOM END PULLEY - PART R (WITH THE RED PULLEY)
INSERT THE TUBING AS FAR AS IT WILL GO - ABOUT 5 INCHES
SLIDE THE END PULLEY ON
WALK AROUND THE MACHINE
AND TIGHTEN EVERYTHING UP
IMPORTANT:
FOOT
SPLIT
FITTINGS
DO A “WALK-AROUND”
13
13
MVP/XXL
ASSEMBLY MANUAL
