Step 5, Swingaway, Mvp/xxl – SwingAway SWGSB100 User Manual
Page 10: Rear telescope
M
N
TIGHTEN
KNOB
INSERT ALL
THE WAY IN
SLIDE THIS PIECE
ALL THE WAY DOWN
BASE ASSEMBLY
O
PART O IS ATTACHED
TO N WITH CORDS
STEP 5
STEP 5
REAR TELESCOPE
FITTING IS
ACTUALLY
BLACK
GOOD TIME TO DOUBLE CHECK
THIS FITTING - MAKE SURE ROPE
GOES THROUGH ALL FOUR HOLES
8
8
MVP/XXL
ASSEMBLY MANUAL
SWINGAWAY
SWINGAWAY
SPORTS PRODUCTS
SPORTS PRODUCTS
SPORTS PRODUCTS
THE "SwingAway®" PRODUCT IS PROTECTED UNDER US PATENTS 5,795,250 AND 7,914,400.
Copyright © SwingAway Sports, LLC 2013 | All Rights Reserved
