Page 14: Very important! level your machine out
STEP 9
STEP 9
VERY IMPORTANT!
LEVEL YOUR MACHINE OUT
TOUCH
FLOOR
TOUCH
FLOOR
TOUCH
FLOOR
KNOB
TIGHT
KNOB
TIGHT
WHILE ON A FLAT SURFACE, ADJUST THE FRAME BY PULLING OR
PUSHING THE TELESCOPING TUBES
MAKE SURE ALL THE FEET ARE TOUCHING THE GROUND
THEN TIGHTEN THE KNOB ON THE MIDDLE TELESCOPE FITTING
KNOB
TIGHT
LOOSE
KNOB
12
12
