— 13 —
Model PPU-700-RK PPU-700-RU PPU-700-RE
Item PPU-700-PK PPU-700-PU PPU-700-PE
Print method Line thermal dot print method
Print width *1 72 mm/576 dots
Dot density 8 × 8 dots/mm (203 dpi)
Print speed 150 mm/sec (max., Print density level 2), (1200 dot lines/sec)
Number of print Font A: 48 columns, 12 × 24 dots
columns Font B: 64 columns, 9 × 17 dots
Font C: 72 columns, 8 × 16 dots
*2
Kanji Font: A 24 columns, 24 × 24 dots
Kanji Font: B 36 columns, 16 × 16 dots
Character size Font A: 1.50 × 3.00 mm
Font B: 1.13 × 2.13 mm
Font C: 1.00 × 2.00 mm
Kanji Font A: 3.00 × 3.00 mm
Kanji Font C: 2.00 × 2.00 mm
Character type Alphanumeric characters, International characters, PC850, 852, 857, 858,
860, 863, 865, 866, WPC1252, Katakana
Kanji (JIS Level 1, Level 2)
User memory 256 KB (Capable of registering user-defined characters and logos)
Barcode type UPC-A/E, JAN (EAN) 13 colummns/8 columns, ITF, CODE 39, CODE 128,
CODABAR, CODE 93
Line spacing 4.23 mm (1/6 in.), selectable by use of command
Paper Thermal paper roll
(See paper spec.) Width: 58 to 82.5 mm
External diameter:
φ203 mm max. (when using PHU)
Internal diameter: φ25.4 mm
Paper thickness: 65 to 150 µm
Presenter Standard length: 90 mm
Interface Serial (RS-232C compliant), Parallel (IEEE1284 compliant), USB
Input buffer 4K bytes/72 bytes
Supply voltage DC 24V ±7%
Power consumption 100 W
AC adapter Rated input: AC 100V to 240V, 50/60 Hz, 150 VA
specification Rated output: DC 24V, 2A
Type 32AD-J 32AD-U 32AD-E
Weight PPU: 1.6 Kg (Including control board)
PHU: 0.9 Kg (Excluding paper roll)
Outside dimensions 145 (W) × 160 (D) × 172 (H) mm (See external view)
Operating temperature 5 to 40°C, 35 to 85% RH (No dew condensation)
and humidity
Storage temperature –20 to 60°C, 10 to 90% RH (No dew condensation)
and humidity
2.2 Basic Specifications
