background image

Instruction Manual

5

1. Adjust the local computer to a lower resolution and refresh rate until all remote

displays show an image.

2. Gradually increase the resolution and refresh rate on the local computer until one

(or more) remote displays ceases to display an image.

3. Return the resolution and refresh rate on the local computer to the highest

resolution and refresh rate setting that displayed an image on all remote displays.

NOTE: If you are still unable to see an image on a remote display after trying the above

solutions, it is recommended that you verify the Category 5 Ethernet cable installation

to the remote display before calling technical support. This can be done using a

standard cable tester. If you do not have a cable tester, contact a local computer

service or wiring professional.

Specifications

Resolution

Up to 1280x1024 @60Hz (can be

affected by overall cable length)

Sync

TTL Compatible

Horizontal/Vertical Sync Polarity

Positive/Negative

System Cable Maximum Distance

Category 5 Shielded FTP Cable 1000 feet

(300 meters)

Connectors

ST124UTPE: 4 x Cat. 5

1 x HD-15 VGA (in)

1 x HD-15 VGA (out)

ST128UTPE: 8 x Cat. 5 (out)

1 x HD-15 VGA (in)

1 x HD-15 VGA (out)

Power

External Adapter: 12V DC 600mA

Dimensions (LxWxH) mm

ST124UTPE: 130 x 83.5 x 29.5
ST128UTPE: 200 x 83.5 x 29.5

Weight

ST124UTPE: 247g
ST128UTPE: 345g
