Source Audio Soundblox 2 Stingray Multi-Filter - Manual (Page 3)

Stingray Manual - pages 26,3
26 | Specifications
Dimensions
• L: 4.5 inches
• W: 4.5 inches
• H: 2.25 inches (including knobs)
Weight
• 1.00 lbs
Power
• 140mA @ 9V DC (max 180mA with Hot
Hand Wireless Adapter)
• Negative tip power jack
Audio Performance
• Maximum input level: 2.0 Vrms (+6 dBV)
• Input impedance: 1 MOhm
• Output impedance: 1 kOhm
• 115dB DNR audio path
• 24-bit audio conversion
• 56-bit digital data path
• Universal Bypass™ (buffered or relay-
based true bypass)
SPECIFICATIONS
TROUBLESHOOTING
Noise:
Power Source Ensure that the proper power supply is being used.
Near noise source Move pedal away from power supplies and other equipment.
Other equipment Remove other effects from signal chain, see if noise persists.
Bad cables Swap out audio cables.
Hot Hand doesn’t work:
Low power Ensure that the proper power supply is being used.
Not calibrated properly Calibrate the Hot Hand — see page 24.
Not connected properly Check Hot Hand connections.
Overview | 3
OVERVIEW
DIVERSE SOUND PALLETE: Features up to 24 different Low Pass, Single
Peak, Multi-Peak, High Pass, and Phaser effects.
DEEP CONTROL SET: Access to control parameters typically found only
on professional rack-mount systems.
DRIVE/DISTORTION: Add gain and distortion to any of the STINGRAY’s
effects for an added boost and flavor.
STATE-OF-THE-ART DSP: Our proprietary 56-bit Digital Signal
Processor, the SA601, and crystal clear 24-bit converters.
COMPACT DESIGN: A compact, rugged, cast-aluminum housing.
UNIVERSAL BYPASS: Select either analog buffered or relay-based True
Bypass.
2 USER PRESETS: Easy-to-program user presets recallable via two
footswitches.
MULTI-FUNCTION INPUT: A multi-purpose control input for use with Hot
Hand, the Source Audio Dual Expression Pedal, or send and receive MIDI
information via the Soundblox HUB.
General:
Restore Factory Settings Press and hold CONTROL INPUT button while powering on
the pedal until each preset footswitch LED blinks.
