I N S T R U C T I O N M A N U A L • M O D E L G X T P O W E R S U P P LY
22
Go To Top Of Document
A D D I T I O N A L F E A T U R E S A N D F U N C T I O N S
JOB STORAGE
Up to 15 different jobs may be stored and recalled or changed upon demand.
Typical job parameters stored include Time and Power, Force Trigger, Limits,
and Amplitude.
Save
To use the job storage feature, press the Recall/Save key. If the “recall”
option is displayed on the screen press the button again. The Save display
appears as follow:
Saved jobs will be numbered 01 through 15. To save a job, use the numerical
keys to enter in the desired job number (01 – 15). Once the job number is
keyed in, press the ENTER key. All the parameters for that job will be saved
under the job number keyed in. The system will return to the ready screen.
Recall
To recall a job that has been saved, press the Recall/Save key. If the “save”
option is displayed on the screen press the button again. The Recall display
appears as follow:
Recalled jobs are numbered 01 through 15. To recall a job, use the numerical
keys to enter in the desired job number (01 – 15). Once the job number is
keyed in, the settings for that job will be displayed on the various parameter
menus.
The System will not respond if there is no job saved under a number
corresponding to the numerical key pressed.
Save to Job #
— —
Recall from Job #
— —
