I N S T R U C T I O N M A N U A L • M O D E L G X T P O W E R S U P P LY
15
5. DISTANCE key. Option not available with Model GXT.
6. ENERGY key. Option not available with Model GXT.
7. A M P L I T U D E / P R E S S U R E key which controls adjustment of the
following amplitude and pressure settings of the system’s high-frequency
vibrations over the full operating range. (Major adjustments of amplitude
can be made through the use of different boosters – consult your press
manual for further information.)
a. Amplitude Setting
b. Amplitude Ramp (only on systems configured for more than 2200
watts)
c. Trigger Force (Press)
8. TRIGGER key which displays and permits selection of the trigger mode
from the following options –
a. Delay Timer
b Force/Pressure
c. Pretrigger - Top
9. RECALL/SAVE key which allows up to 15 different jobs to be stored
(saved) and recalled or changed upon demand.
10. ARROW keys (Up/Down) which allow scrolling through some menus and
also serve as a toggle for displayed parameter options in some menus.
11. TEST key which can be used to test ultrasonic operation and displays
idle losses of converter/booster/horn as a percentage of maximum power
when key is depressed. Also functions as a frequency display.
12. O.L. RESET key which resets the power supply following an overload
condition. Red LED in upper left corner indicates an overload condition
exists.
13. 0-9 NUMERIC KEY PAD which allows input of numeric data or
numeric selection options by pressing the keys.
14. CLEAR key which cancels a prior parameter value when a new value is
to be entered.
15. ENTER/REVIEW key which Enters data into the system as keyed in with
the numerical keys and displayed on the LCD screen. In Review function,
displays the alarm, mode and cycle information.
