ZCS-232 User Guide
8
End Device End Device
Coordinator
End Device
End Device
To use one coordinator with several end devices, all the end devices should be set with the PAN ID and
channel of the coordinator. Additionally, to communicate among end devices, each devices should have a
unique ID as a source ID and the ID from the device trying to send the data should be set in the destination
ID.
Following is an example of 1:N ZCS-232 connection using ZCS Configuration Utility.
