ZCS-232 User Guide
10
8. Configure ZCS-232
A. Setup Mode
To modify the settings in ZCS-232, mode switch in ZCS-232 should be set to “SETUP” and the power must
be supplied. If you were using ZCS-232, but needed to enter the setup mode, change the mode from
ACTIVE to SETUP. Then unplug the power and replug it to apply the setup mode.
B. Active Mode
After setting configuration for your ZCS-232, set the mode switch from “SETUP” to “ACTIVE”. Then
click on the Reset button from the ZCS Configuration Utility or unplug the power and replug it to apply the
active mode.
C. Add Device
Run ZCSConfig.exe to see the window shown as below. To add a device, click on the “Add Device” button.
