Preface
Thank you for purchasing product by SystemBase. This product has passed thorough quality control and
during the 5 years warranty period, the customers can receive free repair services from the day the purchase
was made. If you have any questions or difficulties with this product please contact our Technical Support
by submitting an inquiry
1.
Feature
ZCS-232 is a Serial-to-ZigBee Converter which allows ZigBee (IEEE 802.4.15) communication in Serial
(RS-232) environment with providing coordinator, router, and end device features.
2.
Specification
RF Section
Standard
IEEE 802.15.4 ZigBee Pro Standard (250kbps)
Compatible with ZigBee Standard
Modulation
DSSS
Flash Size
256KB
Security
AES
Operating voltage
2 ~ 3.6 V
Antenna
1.5 dB Stub Antenna provided
Serial Section
Interface
RS-232
Signal used
TXD, RXD, CTS, RTS, DTR, DSR
Speed
Max. 250kbps
Hardware & Operating Environment
Operation Voltage
+5 ~ + 9VDC (non-polar)
Adapter
+9V DC, 300mA, ф3.47mm (USB-to-DC Cable provided)
Power Consumption
Max. 0.5W
LED Information
Link, SRL, RDY
Operation Temperature
-40℃ ~ +85℃
Operation Humidity
5 ~ 95%, non-condensing
