Mounting, Figure 5 : cabinet installation, Figure 6 : circuit board mounting – SilentKnight 5883 Relay Interface Board User Manual
Page 4
Model 5883 Installation Instructions
4
P/N 151194 Rev A
Mounting
Mount the cabinet as shown in Figure 5. Install
the 5883 circuit board as shown in Figure 6.
Figure 5: Cabinet Installation
Figure 6: Circuit Board Mounting
Mounting
Holes
Mounting
Holes
Cabinet
Included
Mounting
Screw
Mounting
Screw
