7.0 field strip disassembly
1. unload and clear the rifle per section 5.0.
2. ensure the bolt carrier assembly is forward and the fire control selector is placed on Safe.
3. Press the takedown pin from left to right until it stops (it is held into the lower receiver by a detent and will not pull free
from the receiver).
FIG 27 the takedown PIn and PIvot PIn
takedown Pin
Pivot Pin
