Tank:
. Select position in bathroom where unit can be
installed in socket fitting and operate properly.
Allow room for using the flush lever and clearance
for raising the seat and lid.
2. Position the tank against three walls. Mark four
holes at mounts on tank base. After holes are
marked, remove tank, and drill pilot holes. Slide
tank back into position. Secure the tank with four
screws and washers on all tank mounts.
3. Insert -/2 inch (38mm) I.D. PVC vent pipe into a
rubber sealing grommet in either corner of the tank,
no more than /2 inch (3mm) into tank. Be sure to
plumb vent pipe correctly to desired outside location.
SpeCIfICATIoNS
product Name: 72-TM09 SeaLand Toilet
System:
Average water consumption per flush . qt. (.95 L)
Minimum water consumption per flush. pt. (.47 L)
Holding tank capacity . . . . . . . . . . . . .9 gal. (34. L)
Water supply pressure . 5-80 PSI (.35-5.62 Kg/cm
2 )
Water inlet size . . . . . . . . . . . . . . /2" (3 mm) NPT
Holding tank discharge fitting . . . .3" (76 mm) spigot
Vent fitting. . . . . . . . for -/2" (38 mm) ID PVC pipe
Unit weight . . . . . . . . . . . . . . . . . . . . 4 lbs. (9 Kg)
Dimensions:
INSTALLATIoN INSTRuCTIoNS
Overall height
with seat lid up is
31 1/4-inch
(794mm)
All dimensions +/-3/8-inch (10mm)
