SeaLand VacuFlush Toilet Specifications
5.3 Toilet installation specifications
Electrical
Amp draw (average) 2 amps at 12 V DC; 1 amp at 24 V DC
Fuse 2-amp internal fuse (resettable)
Water
Supply
Fitting 0.5 in. NPT
Flow rate 2.0 gpm/7.6 lpm minimum required at toilet
Discharge
Size 1.5 in./38 mm ID PVC pipe or sanitation hose
Horizontal run 50 ft./15 m maximum to vacuum source
Vertical run 6 ft ./1 .8 m maximum to vacuum source
Required
components
Electric flush switch Dometic, Vimar or Gewiss (purchased separately)
Vacuum source
VacuFlush vacuum generator or
VacuFlush holding tank system (purchased separately)
Specifications subject to change without notice.
5.4 Dimensions (fig . 3 , page 2) All dimensions may vary ± 0.375 in. / 10 mm
Ref. Dimension
A 18.125 in. / 460 mm
B 14 .75 in . / 375 mm
C 18 .625 in . / 473 mm
D 17 in . / 432 mm - seat height
E 15.75 in. / 400 mm
F 8.625 in. / 219 mm - rough-in (4809)
G 33 .5 in . / 851 mm - seat lid up
Ref. Dimension
A 14 .75 in . / 375 mm
B 14 .75 in . / 375 mm
C 18 .25 in . / 464 mm
D 13 .625 in . / 346 mm - seat height
E 14 .875 in . / 378 mm
F 8.375 in. / 213 mm - rough-in (4806)
G 30.25 in. / 768 mm - seat lid up
Models 4809, 4848, 4828, 4829 Model 4806, 4826
Ref. Dimension
A 18 in . / 457 mm
B 14 .75 in . / 375 mm
C 19.75 in. / 502 mm
D 17 in . / 432 mm - seat height
E 16 in. / 406 mm
F 10.5 in. / 267 mm - rough-in (4609)
G 33 .5 in . / 851 mm - seat lid up
Ref. Dimension
A 15 in . / 381 mm
B 14 .75 in . / 375 mm
C 19.75 in. / 502 mm
D 14 in . / 356 mm - seat height
E 15 .375 in . / 391 mm
F 10.375 in. / 264 mm - rough-in (4606)
G 30.5 in. / 775 mm - seat lid up
Models 4609, 4648 Model 4606
