5
SeaLand VacuFlush Toilet Components
4 Components
4.1 VacuFlush all-ceramic toilet
(fig . 1 , page 2) (fig . 2 , page 2)
Ref. Description
1 Service mode switch
2 Water supply check valve
3 Electric water valve
4 Water supply line
5 Plug-in discharge fitting
6 Circuit board
7 Flush ball motor/drive linkage
Refer to complete parts list (packed separately) for
additional information .
Ref. Description
A VacuFlush switch/status panel
B VacuFlush touchpad
C Vimar flush switch/status panel
D Gewiss flush switch/status panel
VacuFlush all-ceramic toilets operate with selection of
VacuFlush, Vimar and Gewiss flush switches.
Models vary .
4.2 Typical VacuFlush toilet system (marine)
(fig . 4 , page 2)
Ref. Description
1 VacuFlush all-ceramic toilet
2 VacuFlush switch/status panel
3 Vacuum generator
4 Holding tank status panel
5 Holding tank (waste)
Ref. Description
6 Vent filter
7 Discharge pump
8 Overboard discharge fitting
9 Air vent fitting
10 Dockside discharge fitting
Some VacuFlush toilet systems combine the vacuum generator (3) and holding tank (5) into one unit (VacuFlush holding tank system).
Contact boat or vehicle manufacturer for complete information on your toilet system .
5 Specifications
5.1 Materials
Toilet body: vitreous ceramic Discharge fitting: polypropylene
Toilet seat: thermoset plastic resin or wood (seats vary according to toilet model)
5.2 Approvals
CE and ROHS compliant components
