Arge, Perture, Alorimeter – Scientech S310 Vector User Manual
Page 9: Pecifications
9
L
ARGE
A
PERTURE
(100
MM
&
200
MM
)
C
ALORIMETER
S
PECIFICATIONS
:
Model
360401
380401
380402
384UV5
360801
380801
380802
384UV5
Type of Absorber
Surface
Volume
Volume
Volume
Surface
Volume*
Volume
Volume
Aperture Diameter
100mm
200mm
Minimum Beam Diameter
Spectral Response
.25 - 35µm .266 - 1.2µm
9 -11µm
.193 - .36µm .25 - 35µm .266 - 1.2µm
9 -11µm
.193 - .36µm
Maximum Average Power
50W with full illumination of absorbing surface
100W with full illumination of absorbing surface
Minimum Average Power
150mW
700mW
Noise Level
1.5mJ - mW
7mJ - mW
Maximum Power Density
200W/cm²
See Note 1
4W/cm²
Note 2
200W/cm²
See Note 3
4W/cm²
Note 2
Maximum Peak Power Density
1MW/cm²
See Note 4 100MW/cm² See Note 5
1MW/cm²
See Note 6 100MW/cm² See Note 5
Maximum Single Pulse Energy
Maximum Energy Density
Note 7
Note 8
4J/cm
2
Note 9
Note 7
Note 10
4J/cm
2
Note 9
Precision
< 1%
Accuracy
5%
Response Time
5 sec when connected to a Scientech Indicator in Watts Mode
Dimensions DxL - inches/cm
6.00 x 8.00/15.24 x 20.32
9.00 x 10.00/22.86 x 25.40
Weight - pounds/kgs
6/2.72
16.27/7.26
Indicator Compatibility
H410, H410D, S310, S310D
* This is a segmented absorber
Note 1: 380401
27W/cm
2
@ 1064 nm, 21W/cm
2
@ 532 nm, 7.7W/cm
2
@ 355 nm, 158mW/cm
2
@ 266nm
Note 2: 384UV5, 388UV5
50W/cm
2
@ 355nm
Note 3: 380801
13.5W/cm
2
@ 1064 nm, 10.5W/cm
2
@ 532 nm, 3.85W/cm
2
@ 355 nm, 79mW/cm
2
@ 266nm
Note 4: 380401
90GW/cm
2
@ 1064 nm, 71GW/cm
2
@ 532 nm, 27GW/cm
2
@ 355 nm, 530MW/cm
2
@ 266nm
Note 5: 384UV5, 388UV5
Repetitive pulses: 101MW/cm
2
@ 355nm
Single pulses: 3.5GW/cm
2
@ 355nm
Note 6: 380801
45GW/cm
2
@ 1064 nm, 35.5GW/cm
2
@ 532 nm, 13.5GW/cm
2
@ 355 nm, 265MW/cm
2
@ 266nm
Note 7: 360401, 360801
Max J/cm
2
= 1000 x (pulse width)
1/2
to a maximum of 200J/cm
2
Note 8: 380401
Repetitive pulses:
3.7J/cm
2
@ 1064nm, 2.9J/cm
2
@ 532nm, 1J/cm
2
@ 355nm, 20mJ/cm
2
@ 266nm
Single pulses:
7J/cm
2
@ 1064nm, 5.6J/cm
2
@ 532nm, 2.1J/cm
2
@ 355nm, 41mJ/cm
2
@ 266nm
Note 9: 384UV5, 388UV5
Repetitive pulses: 1.1J/cm
2
@ 355nm
Single pulses: 40J/cm2 @ 355nm
Note 10: 38-0801
Repetitive pulses:
1.85J/cm
2
@ 1064nm, 1.45J/cm
2
@ 532nm, 0.5J/cm
2
@ 355nm, 10mJ/cm
2
@ 266nm
Single pulses:
3.5J/cm
2
@ 1064nm, 2.8J/cm
2
@ 532nm, 1.05J/cm
2
@ 355nm, 20.5mJ/cm
2
@ 266nm
150J
300J
5cm
7.5cm
