A
STRAL
™ C
ALORIMETER
S
PECIFICATIONS
:
Model AC2500 AC25HD ACX25HD AC2501 ACX2501 AC25UV AC2504
Type of Absorber Surface Surface Surface Volume Volume Volume Volume
Maximum Beam Diameter 25 mm 25 mm 8 mm 25 mm 8 mm 25 mm 25 mm
Spectral Response .25-35 µm .193-12 µm .4-2 µm .266-1.2 µm .4-1.2 µm .193-.36 µm .85-4.2 µm
Average Power Maximum 10 W
Average Power Minimum 1 mW when installed in an Isoperibol Enclosure
Noise Level 10 µW or µJ
Maximum Power Density 200 W/cm² 1.5 kW/cm² 12 kW/cm² Note 1 Note 2 Note 3 Note 4
Maximum Peak Power Density 1 MW/cm² 100 MW/cm² 800 MW/cm² Note 5 8.5 GW/cm² Note 6 Note 7
Maximum Single Pulse Energy 10 J
Maximum Energy Density Note 8 Note 9 Note 10 Note 11 Note 12 Note 13 Note 14
Precision < 1 %
Accuracy ± 3 %
Response Time 3 sec when connected to a Scientech Indicator in Watts Mode
Dimensions DxL - inches 3.75 x 2.2 3.75 x 2.2 3.75 x 3.82 3.75 x 2.2 3.75 x 3.82 3.75 x 2.2 3.75 x 2.2
cm 9.53 x 5.6 9.53 x 5.6 9.53 x 9.7 9.53 x 5.6 9.53 x 9.7 9.53 x 5.6 9.53 x 5.6
Weight - pounds/kg 1.5/0.68 1.5/0.68 1.7/0.77 1.5/0.68 1.7/0.77 1.5/0.68 1.5/0.68
Indicator Compatibility H410, H410D, S310, S310D, D200PC, D200C
Model AC5000 AC50HD ACX50HD AC5001 ACX5001 AC50UV AC5004
Type Absorber Surface Surface Surface Volume Volume Volume Volume
Maximum Beam Diameter 50 mm 50 mm 16 mm 50 mm 16 mm 50 mm 50 mm
Spectral Response .25-35 µm .193-12 µm .4-2 µm .266-1.2 µm .4-1.2 µm .193-.36 µm .85-4.2 µm
Average Power Maximum 30 W
Average Power Minimum 40 mW
Noise Level 400 µW or µJ
Maximum Power Density 200 W/cm² 1.5 kW/cm² 12 kW/cm² Note 1 Note 2 Note 3 Note 4
Maximum Peak Power Density 1 MW/cm² 100 MW/cm² 800 MW/cm² Note 5 8.5 GW/cm² Note 6 Note 7
Maximum Single Pulse Energy 30 J
Maximum Energy Density Note 8 Note 9 Note 10 Note 11 Note 12 Note 13 Note 14
Precision < 1 %
Accuracy ± 3 %
Response Time 3 sec when connected to a Scientech Indicator in Watts Mode
Dimensions DxL - inches 4.75 x 2.3 4.75 x 2.3 4.75 x 3.92 4.75 x 2.3 4.75 x 3.92 4.75 x 2.3 4.75 x 2.3
cm 12.07 x 5.8 12.07 x 5.8 12.07 x 9.96 12.07 x 5.8 12.07 x 9.96 12.07 x 5.8 12.07 x 5.8
Weight pounds/kgs 2.9/1.3 2.9/1.3 3.1/1.4 2.9/1.3 3.1/1.4 2.9/1.3 2.9/1.3
Indicator Compatibility H410, H410D, S310, S310D, D200PC, D200C
Note 1: AC2501, AC5001 30W/cm 2 @ 1064nm, 23W/cm 2 @ 532nm, 8.5W/cm 2 @ 355nm, 175mW/cm 2 @ 266nm
Note 2: ACX2501, ACX5001 Note 1 specs x 8 for 400nm to 1.2µm
Note 3: AC25UV, AC50UV 50W/cm 2 @ 355nm
Note 4: AC2504, AC5004 35W/cm 2 @1064nm
Note 5: AC2501, AC5001 100GW/cm 2 @ 1064nm, 78GW/cm 2 @532nm, 29GW/cm 2 @ 355nm, 580MW/cm 2 @266nm
Note 6: AC25UV, AC50UV Repetitive pulses: 101MW/cm 2 @ 355nm
Single pulses: 3.5GW/cm2 @ 355nm
Note 7: AC2504, AC5004 125GW/cm 2 @ 1064nm
Note 8: AC2500, AC5000 Max J/cm 2 = 1,000 x (pulse width) 1/2 to a maximum of 200J/cm 2 .
Note 9: AC25HD, AC50HD Max J/cm 2 = 4,500 x (pulse width) 1/2 to a maximum of 14J/cm 2 .
Note 10: ACX25HD, ACX50HD Max J/cm 2 = 36,000 x (pulse width) 1/2 to a maximum of 42.5J/cm 2 .
Note 11: AC2501, AC5001 Repetitive pulses: 4.1J/cm 2 @1064nm, 3.2J/cm 2 @532nm, 1.2J/cm 2 @355nm, 24mJ/cm 2 @266nm
Single pulses: 8J/cm 2 @1064nm, 6.2J/cm 2 @532nm, 2.3J/cm 2 @355nm, 46mJ/cm 2 @266nm
Note 12: ACX2501, ACX5001 Note 11 specs x 8 for 400nm to 1.2µm
Note 13: AC25UV, AC50UV Repetitive pulses: 1.1J/cm 2 @ 355nm
Single pulses: 40J/cm2 @ 355nm
Note 14: AC2504, AC5004 Repetitive pulses: 4.8J/cm 2 @ 1064nm
Single pulses: 10J/cm2 @ 1064nm
