Scientech 12000 Series - Manual (Page 23)

23
Specifications for SA Analytical Balances:
Note: Balances with an Internal Calibration Weight have an “IW” suffix in their model number. Their specifications are the same as the models in the table below.
Model SA 80 SA 120 SA 210 SA 310 SA 410 SA 510 SA 210D SA 525D
Weighing Mode Single Range Dual Range
(Floating Tare™)
Capacity 80g 120g 210g 310g 410g 510g 100g 250g
200g 500g
Readability .0001g .0001g
.001g
Tare Range 0-80g 0-120g 0-210g 0-310g 0-410g 0-510g 0-200g 0-500g
0-200g 0-500g
Repeatability .0001g .0001g .0001g .00015g .00015g .0002g .0001g .00015g
(Standard Deviation) .0005g .0005g
Linearity ±.0002g ±.0002g
±.0005g
Stabilization Time User Selectable
Weighing Speed Adaptive
Display Update Interval 200ms
Data Interface RS-232 bidirectional interface is standard. Baud rates are 300, 600, 1200, 2400, 4800, 9600 and 19,200.
Pan Size Circular 3.5 inch diameter
Operating Temperature 5°C to 40°C
Relative Humidity 80 % for temperatures up to 31°C decreasing linearly to 50 % at 40°C
Power Supply 115 Volts/60 Hz ± 10 %
230 Volts/50Hz or 60 Hz ± 10 %
Windscreen 7.5W x 8.25D x 9.5H
Calibration Weight 80g 100g 200g 300g 400g 500g 200g 500g
50g 50g 100g 200g 200g 100g 200g
Housing (WxDxH) 7.5" x 11.25" x 3.25"
Weight ~ 13.8 lbs
