7
(*)R6GN Single Package Gas Heating / Electric Cooling Rooftop Units
ITEM DESCRIPTIoN
(*)R6GN-150*XXXC (*)R6GN-180*XXXC
920297 920298 920299 920300 920301 920302 920303 920304
208/230V
3 Ph.
460 V
3 Ph.
208/230V
3 Ph.
460V
3 Ph. 208/230V
3 Ph.
460 V
3 Ph.
208/230V
3 Ph.
460V
3 Ph.
INDIVIDUAL BLoWER CoMPoNENTS (ITEMS 83 - 87)
83 Bearing, Drive, Pillow Block, 1-3/16” Dia. 667349 667349 667349 667349 667349 667349 667349 667349
84 Wheel, Blower, 12” x 12” x 1-3/16” 667346 667346 667346 667346 667346 667346 667346 667346
85 Shaft, Blower Drive, 1-3/16” Dia. 667347 667347 667347 667347 667347 667347 667347 667347
86 Bearing, Sealed Ball,1-3/16” Dia. 667348 667348 667348 667348 667348 667348 667348 667348
87 Bearing Bracket, Blower 669481 669481 669481 669481 669481 669481 669481 669481
88 Filter, 16” x 20” x 2”, Pleated 668940 668940 668940 668940 668940 668940 668940 668940
89
Coil Assembly, Indoor, 12.5T (Includes TXV's) M0041644R M0041644R M0041644R M0041644R - - - -
Coil Assembly, Indoor, 15T (Includes TXV's) - - - - M0041645R M0041645R M0041645R M0041645R
90
TXV Replacement, 12.5T TXV w/ 13 Crkt Distributor 669792R 669792R 669792R 669792R - - - -
TXV Replacement, 15.0T TXV w/ 13 Crkt. Distributor - - - - 669793R 669793R 669793R 669793R
91 Slide Latch 632423 632423 632423 632423 632423 632423 632423 632423
92 Terminal Board, Low Voltage, 3 Pin 632420 632420 632420 632420 632420 632420 632420 632420
93 Switch, Limit - Secondary, 120/100 626535 626535 626535 626535 626535 626535 626535 626535
94 Bracket, Main Air Limit 282361 282361 282361 282361 282361 282361 282361 282361
95 Switch, Limit, Main Air - Primary, 200/160 626534 626534 626534 626534 626534 626534 626534 626534
96 Drier, Liquid Line, 304S 669791 669791 669791 669791 669791 669791 669791 669791
97 Valve, Service, 1/2” 663594 663594 663594 663594 663594 663594 663594 663594
98 Valve, Service, Dual Port, 3/4” 663961 663961 663961 663961 663961 663961 663961 663961
99 Low Pressure Switch Assembly M0041667 M0041667 M0041667 M0041667 M0041667 M0041667 M0041667 M0041667
100 High Pressure Switch Assembly M0041666 M0041666 M0041666 M0041666 M0041666 M0041666 M0041666 M0041666
101
Coil Assembly, Outdoor, 12.5T, 2 Row -
40” x 75”
299481R 299481R 299481R 299481R - - - -
Coil Assembly, Outdoor, 15.0T, 3 Row -
40” x 75”
- - - - 2A0361R 2A0361R 2A0361R 2A0361R
