(*)R6GN Single Package Gas Heating / Electric Cooling Rooftop Units
ITEM DESCRIPTIoN
(*)R6GN-150*XXXC (*)R6GN-180*XXXC
920297 920298 920299 920300 920301 920302 920303 920304
208/230V
3 Ph.
460 V
3 Ph.
208/230V
3 Ph.
460V
3 Ph. 208/230V
3 Ph.
460 V
3 Ph.
208/230V
3 Ph.
460V
3 Ph.
38
Complete Heat Exchanger Assy. - 4 tube 663974 663974 - - - - - -
Complete Heat Exchanger Assy. - 6 tube - - 663976 663976 663976 663976 - -
Complete Heat Exchanger Assy. - 7 tube - - - - - - 663977 663977
39 Spark Ignitor 632437 632437 632437 632437 632437 632437 632437 632437
40 Switch, Limit, Flame Roll Out, 280F Man. Reset 626536 626536 626536 626536 626536 626536 626536 626536
41 Flame Sensor 632438 632438 632438 632438 632438 632438 632438 632438
42 Switch, Air Pressure 632439 632439 632439 632439 632439 632439 632439 632439
43
Complete Burner Box Assy. - 4 tube 661109 661109 - - - - - -
Complete Burner Box Assy. - 6 tube - - 661111 661111 661111 661111 - -
Complete Burner Box Assy. - 7 tube - - - - - - 661112 661112
44
Bracket, Burner Mounting - 4 Tube 661113 661113 - - - - - -
Bracket, Burner Mounting - 6 Tube - - 661115 661115 661115 661115 - -
Bracket, Burner Mounting - 7 Tube - - - - - - 661116 661116
45 Inshot Burner,3.25”x6.75” w/ .70” insert 661117 661117 661117 661117 661117 661117 661117 661117
46
Orifice, Main Burner
(1/8” DMS) (Nat. Gas 0-2000 Ft.)
661118 661118 661118 661118 661118 661118 661118 661118
47
Manifold Pipe Assy. - 4 Tube 664182 664182 - - - - - -
Manifold Pipe Assy. - 6 Tube - - 664184 664184 664184 664184 - -
Manifold Pipe Assy. - 7 Tube - - - - - - 664185 664185
48 Elbow, 3/4” FPT X 90 Deg. B.I. 664005 664005 664005 664005 664005 664005 664005 664005
49 Combustion Air Tube Assy. M0017515R M0017515R M0017515R M0017515R M0017515R M0017515R M0017515R M0017515R
50
Complete Draft Inducer w/ Housing - 4 Tube 622117 622117 - - - - - -
Complete Draft Inducer w/ Housing - 6 Tube - - 622119 622119 622119 622119 - -
Complete Draft Inducer w/ Housing - 7 Tube - - - - - - 622120 622120
51
Pipe, 3/4” x 18” SCH.40 B.I. 664172 664172 - - - - - -
Pipe, 3/4” x 25” SCH.40 B.I. - - 664004 664004 664004 664004 664004 664004
52
Gas Valve - 2 Stage (Natural) 624695 624695 624695 624695 624695 624695 624695 624695
Gas Valve - 2 Stage (L.P./High Elev.)
Field Conversion Kit
- - - - - - - -
53 Drain Pipe Assembly 664006 664006 664006 664006 664006 664006 664006 664006
54
Capacitor, Run, 12.5 mfd / 370 Volt 622134 622134 622134 622134 - - - -
Capacitor, Run, 7.5 mfd / 370 Volt - - - - 622132 622132 622132 622132
55 Guard, Grille, Right 669789 669789 669789 669789 669789 669789 669789 669789
56 Guard, Grille, Left 669790 669790 669790 669790 669790 669790 669790 669790
57 Fuse Block, 30A / 600V, 3 Pole 632569 632569 632569 632569 632569 632569 632569 632569
58 Fuse, 30A, 600V, TD, Class J 632570 632570 632570 632570 632570 632570 632570 632570
59 Cable, High Voltage Ignition (Not Shown) 632611 632611 632611 632611 632611 632611 632611 632611
60 Spark Ignition Control 624710 624710 624710 624710 624710 624710 624710 624710
61 Contactor, Outdoor Fan Motor - 2 Pole 20A 621668 621668 621668 621668 621668 621668 621668 621668
62 Contactor, Compressor, 3 Pole 30A w/Aux. Sw. 621832 621832 621832 621832 621832 621832 621832 621832
63 Contactor, Indoor Blower Motor, 3 Pole 30A 621667 621667 621667 621667 621667 621667 621667 621667
64 Switch, Limit, Freezestat 626537 626537 626537 626537 626537 626537 626537 626537
65 Terminal Board 3 Pole 632572 632572 632572 632572 632572 632572 632572 632572
66 Dual Ground Lug 632235 632235 632235 632235 632235 632235 632235 632235
67 Terminal Block - High Voltage 632366 632366 632366 632366 632366 632366 632366 632366
68
Overload Relay Adaptor, 3RU1916 Series 622032(#) 622032(#) 622032(#) 622032(#) - 622032 - 622032
Overload Relay Adaptor, 3RU1926 Series - - - - 622083 - 622083 -
69
Relay, Overload, 3 PH, 7.0 - 10.0 Amp 622077(#) - 622077(#) - - - - -
Relay, Overload, 3 PH, 3.5 - 5.0 Amp - 622075(#) - 622075(#) - - - -
Relay, Overload, 3 PH, 11.0 - 16.0 Amp - - - - 622082 - 622082 -
Relay, Overload, 3 PH, 5.5 - 8.0 Amp - - - - - 622031 - 622031
NoTE: (#) Overload relays not required on R6GN-150* models equipped with 3 HP premium efficient motors having internal thermal protection.
