3
R6GF (A SERIES) SINGLE PACKAGE GAS HEATING / ELECTRIC COOLING UNITS
ITEM DESCRIPTION
2 TON 3 TON 4 TON 5 TON
X24K080XA X36K100XA X48K120XA X60K120XA
921232A 920905A 920906A 920907A
36 BRACKET, EXT. SERV PT, HI–FLOW 298552R 298552R 298552R 298552R
37 LIMIT SWITCH, FLAME ROLLOUT 320º F 626547 626547 626547 626547
38 SENSOR, FLAME 632396 632396 632396 632396
39 BURNER, INSHOT 660812 660812 660812 660812
40 REPL. HAIL GUARD KIT (NOT SHOWN) 921213 921213 921213 921213
41
ORIFICE, MAIN BURNER, #43 DRILL (NOT SHOWN) – – 661043 661043
ORIFICE, MAIN BURNER, #45 DRILL (NOT SHOWN) 661045 661045 – –
42
MANIFOLD, GAS, 4 BURNER 664304 – – –
MANIFOLD, GAS, 5 BURNER – 664305 664305 664305
43 DRIER, FILTER, UNIFLOW, 8 IN^3 669764 669764 669764 669764
44 COVER, EXHAUST VENT 265240R 265240R 265240R 265240R
45 PANEL, WEATHER 263880 263880 263880 263880
46 SUPPORT, COIL 263394 263394 263396 263396
47
PAN, COLLECTOR ASSY, 1.35" ORIFICE D10329R – – –
PAN, COLLECTOR ASSY, 1.44" ORIFICE – M0074320R – –
PAN, COLLECTOR ASSY, 1.69" ORIFICE – – M0074321R M0074321R
48 CAPACITOR STRAP 258781 258781 258780 258780
49 COIL, INDOOR D13001R D13001R 2B1961R 2B4001R
50 THERMAL EXPANSION VALVE 664343 664349 664350 664350
51
COMP,COPE,ZPS20K5E-PFV-230 (SEE NOTE) 921844 – – –
COMP,COPE,ZPS20K4E-PFV-230 920334 – – –
COMP,COPE,ZPS30K5E-PFV-230 (SEE NOTE) – 921769 – –
COMP,COPE,ZPS30K4E-PFV-230 – 920335 – –
COMP,COPE,ZPS40K5E-PFV-230 (SEE NOTE) – – 921659 –
COMP,COPE,ZPS40K4E-PFV-230 – – 920336 –
COMP,COPE,ZPS49K5E-PFV-230 (SEE NOTE) – – – 921793
COMP,COPE,ZPS49K4E-PFV-230 – – – 920337
52 SWITCH, HIGH PRESS. – AUTO RESET (NOT SHOWN) 632401 632401 632401 632401
53 FITTING, PANEL MOUNT, HI FLOW 3/8" 664696 664696 664696 664696
54 CORE, PORT, HI, FLOW, BRASS (NOT SHOWN) 664331 664331 664331 664331
55
GAS VALVE, 2-STAGE, NAT. GAS ONLY* 921816 921816 921816 921816
GAS VALVE, 2-STAGE, W/ LP REGULATOR SPRINGS* 921691 921691 921691 921691
56 GROMMET, COMPRESSOR, SCROLL (NOT SHOWN) 668530 668530 668530 668530
57 COMPRESSOR SOUND BLANKET (NOT SHOWN) 689792 689792 689792 689793
58 COIL, OUTDOOR 2B6591R 2B6591R 2B1971R 2B2001R
59 INSULATED TOP RIGHT PAN ASSY M0034707R M0034707R M0034707R M0007286R
60 MOTOR, OUTDOOR FAN 622171 621990 621990 621990
61 FAN, BLADE 667351 667351 667319 667319
62 FAN, GRILLE, 24” 669335 669335 669335 669335
63 GUARD, COIL (FORMED) (NOT SHOWN) 2A8453R 2A8453R 2B4611R 2B4871R
64 COMPRESSOR BOLTS (NOT SHOWN) 600400 600400 600400 600400
65 IGNITOR 903179 903179 903179 903179
66 PANEL, BLOWER DISCHARGE 281493 281493 281495 281495
67 BLOWER SHELF 283932R 283932R 283932R 283932R
68 DIVIDER PANEL BRACKET 2B8241 2B8241 2B8241 2B8241
69 CHANNEL, DRAIN (N/A WITH 1 PIECE TOP PAN) 279722 279722 279722 279722
71 SWITCH, LOW PRESSURE (NOT SHOWN) 632393 632393 632393 632393
72 ACCESS FITTING 663812 663812 663812 663812
73 FAN ORIFICE 295481R 295481R 295481R 295481R
74 CONTROL BRACKET 298591 298591 298591 298591
75 TERMINAL BOARD, LOW VOLTAGE 632475 632475 632475 632475
76 ONE–PIECE TOP PAN M0034722 M0034722 M0034722 M0034723
77 PLUG, MOLDED HV (NOT SHOWN) 634715 634715 634715 634715
Please specify the correct Model No., Serial No, and part number(s) when ordering parts from the nearest authorized dealer or service center.
*Gas valve kit includes necessary wiring harness for field replacement of gas valve P/N 624652 where applicable.
NOTE: Part numbers listed in italics apply to units manufactured ON OR AFTER 04/08/2013.
