2
R6GF (A SERIES) SINGLE PACKAGE GAS HEATING / ELECTRIC COOLING UNITS
ITEM DESCRIPTION
2 TON 3 TON 4 TON 5 TON
X24K080XA X36K100XA X48K120XA X60K120XA
921232A 920905A 920906A 920907A
1 ASSY, CAP, DUCT, HORIZONTAL (NOT SHOWN) 283101R 283101R 283101R 283101R
2 TOP PAN ASSY. – LEFT 293781R 293781R 293781R 293781R
3 CORE, CHARGING PORT (NOT SHOWN) 662103 662103 662103 662103
4 PANEL, HEAT EX. DIVIDER D05072R D05072R D05074R D05074R
5 BOTTOM PAN ASSY D05480R D05480R D05480R D05481R
6 RAIL, BASE, 47.23” LG 277551R 277551R 277551R 277551R
7 RAIL, BASE, 55.63” LG 277552R 277552R 277552R 277552R
8 DIVIDER PANEL ASSY D05504R D05504R M0060704R M0060704R
9 DUCT CAP ASSY. D05530R D05530R D05530R D05530R
10
BLOWER PANEL ASSY, 34” D05542R D05542R – –
BLOWER PANEL ASSY, 42” – – M0060705R M0060705R
11
ASSY, SRV PNL, INSULATED, 34” 296638R 296638R – –
ASSY, SRV PNL, INSULATED, 42” – – M0060703R M0060703R
12 SUPPLY PANEL ASSY D05552R D05552R M0060706R M0060706R
13 RETURN PANEL ASSY D05565R D05565R M0060707R M0060707R
14
CORNER PANEL ASSY, 34” D05628R D05628R – –
CORNER PANEL ASSY, 42” – – M0060708R M0060708R
15
ASSY, CLOSE–OFF PANEL, 34” D05691R D05691R – –
ASSY, CLOSE–OFF PANEL, 42” – – M0060709R M0060709R
16 PAN, DRAIN 669190 669190 669190 669190
17 POST, CORNER D09996R D09996R 2B1941R 2B1941R
18 PANEL, FRONT 298892R 298892R 298894R 298894R
19
BLOWER HSG ASSY, 9/10X10 297214R 297214R – –
BLOWER HSG ASSY, 11X10 – – 297219R 297219R
20
WHEEL, BLOWER 10 X 10 667207 667207 – –
WHEEL, BLOWER 11 X 10 – – 667260 667260
21
MTR, VS, PROG, R6, 1/2HP, 15 SEER, 2 STG, 5.0 (SEE NOTE) M0092712R M0092715R – –
MTR, VS, PROG, R6, 1/2HP, 15 SEER, 2 STG M0074345R M0074346R – –
MTR, VS, PROG, R6, 1HP, 15 SEER, 2 STG, 5.0 (SEE NOTE) – – M0092718R M0092721R
MTR, VS, PROG, R6, 1HP, 15 SEER, 2 STG, 5.0 – – M0074347R M0074347R
22 CONTACTOR 624712 624712 624713 624713
23
TRNSFRM, 208/240/24V, 40VA, 60HZ 622336 622336 622336 –
TRNSFRM, 208/240/24V, 60VA, 60HZ – – – 622335
24
CAPAC, RUN 35/5/370 01-0083 – – –
CAPAC, RUN 40/7.5/370 – 01-0269 – –
CAPAC, RUN 30/7.5/370 (SEE NOTE) – – 01-0263 –
CAPAC, RUN 45/7.5/370 – – 01-0271 –
CAPAC, RUN 40/7.5/440 (SEE NOTE) – – – 01-0292
CAPAC, RUN 80/7.5/370 – – – 01-0279
25 IGNITION / BLOWER CONTROL, 2 STG, 2 SPD 921378 921378 921378 921378
26 PLUG, MOLDED, L, 2–STAGE, (NOT SHOWN) 634682 634682 634682 634682
27 EXHAUST DUCT ASSY. 263420R 263420R 263420R 263420R
28 TOUCH UP PAINT, GREY (NOT SHOWN) 903598 903598 903598 903598
29 INDUCER MOTOR, 2 SPD, 230V 921379 921379 921379 921379
30 SWITCH, PRESSURE, DUAL, NO., .50"/.70"W.C. 632555 632555 632555 632555
31 GASKET, COLLECTOR PAN 689506 689506 689506 689506
32 GASKET, INDUCER MOTOR MOUNTING 689518 689518 689518 689518
33
HEAT EXCH. PANEL ASSY, 4 TUBE M0002536R – – –
HEAT EXCH. PANEL ASSY, 5 TUBE – 293332R M0042501R M0042501R
34
LIMIT SWITCH, MAIN AIR (170/120) 626423 – – –
LIMIT SWITCH, MAIN AIR (140/120) – 626446 – –
LIMIT SWITCH, MAIN AIR (165/145) – – 626432 626432
35
BURNER ASSY, 2 STG VALVE, 4 TUBE M0034105R – – –
BURNER ASSY, 2 STG VALVE, 5 TUBE – 293323 293322 293322
Please specify the correct Model No., Serial No, and part number(s) when ordering parts from the nearest authorized dealer or service center.
NOTE: Part numbers listed in italics apply to units manufactured ON OR AFTER 04/08/2013.
