22
Refrigerant Charging Charts for Heating Mode of Operation
13 SEER Split System Heating Charts
060K OUTDOOR TEMPERATURE (DEG. F)
0 10 20 30 40 50 60
Suc. Liquid Disch. Suc. Liquid Disch. Suc. Liquid Disch. Suc. Liquid Disch. Suc. Liquid Disch. Suc. Liquid Disch. Suc. Liquid Disch.
Press Press. Temp. Press. Press. Temp. Press. Press. Temp. Press. Press. Temp. Press. Press. Temp. Press. Press. Temp. Press. Press. Temp.
31 223 131 44 253 143 57 283 155 70 313 166 82 329 179 95 355 193 107 381 206
32 230 129 45 259 141 58 288 153 71 316 164 83 336 176 96 362 188 108 388 200
33 237 127 46 265 139 59 292 151 72 320 162 84 343 173 97 369 184 109 395 194
34 244 125 47 271 137 60 297 149 73 324 160 85 350 171 98 376 179 110 402 188
35 251 123 48 277 135 61 302 147 74 327 158 86 357 168 99 383 175 111 409 181
36 258 121 49 282 133 62 307 145 75 331 156 87 364 165 100 390 170 112 416 175
37 265 119 50 288 131 63 312 143 76 335 154 88 371 162 101 397 166 113 423 169
