18
Refrigerant Charging Charts for Cooling Mode of Operation
13 SEER Split System Cooling Charts
048K OUTDOOR TEMPERATURE ( deg. F )
70 75 80 85 90 95 100 105
Suc. Press. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
130
132 246 144
134 248 155 269 143
136 249 166 271 153 290 142
138 248 196 273 163 293 151 311 144 329 140
140 249 213 272 185 294 164 315 150 332 147 349 141
142 274 199 296 178 317 159 336 155 353 148 369 142
144 297 191 318 172 339 163 357 154 374 148 389 145
146 320 186 341 172 361 160 378 155 394 151
148 343 183 363 170 383 160 399 156
150 365 180 385 169 404 160
152 387 179 407 169
154 409 178
156
060K OUTDOOR TEMPERATURE ( deg. F )
70 75 80 85 90 95 100 105
Suc. Press. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
124
126 260 140
128 261 151 282 142
130 263 162 284 152 304 144
132 262 186 287 162 307 153 327 148 345 146
134 263 202 287 181 309 164 330 154 349 154 367 149
136 288 195 311 177 333 162 353 162 371 156 389 152
138 312 191 334 175 356 169 375 162 393 158 411 156
140 336 189 358 178 379 168 397 164 415 161
142 360 188 381 178 402 170 420 167
144 383 188 404 179 425 172
146 407 189 427 181
148 430 190
150
