Place lid assembly onto firebox, aligning hinges. Hinges on lid fit inside hinges on firebox. Secure using two hinge pins and
hitch pins.
Vaporiser bar
□
□
and Cooking Grate
Place vaporiser bar onto V-shaped bar rests inside firebox.
Place cooking grate onto firebox.
Hinge Pin
Qty.2
Hitch Pin
Qty.2
NOTE: The vaporiser bar must
be inserted into firebox at an
angle in order to fit beneath
cooking grate supports.
Cooking Grate
Vaporiser Bar
